Socket/Event Distributors (SVE)
Produktbild
SVE 2er-Turm
Bildergalerie
D SVE AbgaenngeD SVE PowerlockD SVE richtig stapelnSVE einzeln SSD
Vorspann

Socket distributors with lots of combination possibilities; can be adapted to meet the special needs of the user, stackable, robust, safe, and with a suitable design - socket/event distributors M-SVE in power stages from 20 to 450 kVA. Indispensable on building sites and at markets, festivals, fairs, theatres, and major events. Suitable for use inside and outside.

Equipment:

Impact-resistant, robust plastic housing in RAL 9017 (black), splash-proof, extremely light and easy to handle, stackable, resistant to weather and ageing, sockets on the front and protected built-in devices on the back (RCD and MCBs), with protection rating IP44, class II - protective-insulated, custom assembly, e.g. in inlet with Powerlock 400 A and as outlet with CEE connectors, 16, 32, 63, and 125 A, quick assembly.

Inhalt

Usage:

Portable power distributors for building sites, events, fairs, sports events, markets, and festivals/fairs.
These distributors are really light and easy to handle. If, for example, four distributors are stacked together, a safe distribution tower can be constructed and can be expanded to make a distribution wall.

Please note:

The feed-in can take place via a connection cable with CEE connectors, a Powerlock, or a Multi-Contact connector. The connected loads range from 44 to 277 kVA. All sockets up to 63 A and all built-in devices are inside the housing profile and are thus protected from mechanical damage. The distributors can be configured to meet individual customer requirements. Just ask us!

Always specify the required type for orders with a Powerlock feed-in.



Type Order number Connected laod kVA Power supply Sockets RCDs



Powerlock CEE-supply cable H07RN-F, 1m with CEE plug 400V / 5-polig CEE-Sockets
      A IN (A) / A (mm²) 16A5p 400V6h 32A5p 400V6h 63A5p 400V6h 125A
400V6h
16A3p 230V Sockets 250V
M-SVE3 16/3-6 MZ80020 11   16/2,5 3         6 40/0,03A
M-SVE3 32/11-12 MZ80030 22   32/4 1 1       12 40/0,03A
M-SVE3 63/121-9 MZ80000 44   63/10 1 2 1     9 63/0,03A
M-SVE3 63/11-12 MZ80011 44   63/10 1 1       12 2x63/0,03A
M-SVE3 63/0-18 MZ80002 44   63/10           18 2x63/0,03A
M-SVE3 63/0-5-12 MZ80006 44   63/10         5 12 3x40/0,03A
M-SVE4 63/121-15 MZ80012 44   63/10 1 2 1     15 2x63/0,03A
M-SVE4 125/222-6 MZ80013 87   125/35 2 2 2     6 63/0,03A; 2x63/0,3A
M-SVE4 125/012-6 MZ80007 87   125/35   1 2     6 63/0,03A; 2x63/0,3A
M-SVE4 400/0022-0 MZ80005 277 400       2 2     2x63/0,3A; 2x125/0,5A
M-SVE4 400/0004-0 MZ80008 277 400         4     4x125/0,5A
M-SVE4 TG MZ80100 Accessories: Base frame for SVE4
M-SVE3 TG MZ80101 Accessories: Base fram for SVE3
